| Nr. |
Part-Nummer |
Beschreibung |
Menge |
| |
06110-NL9-000 |
ENGINE POWER UP KIT I |
1 |
| 1 |
14110-MEL-R10 |
CAMSHAFT COMP,IN |
1 |
| 2 |
14210-MEL-R10 |
CAMSHAFT COMP,EX |
1 |
| 3 |
14751-MEL-R10 |
SPG,IN VALVE |
8 |
| 4 |
22401-MEL-R10 |
SPRING,CLUTCH |
5 |
| 5 |
31910-NL3-620 |
PLUG,SPARK,R0045Q-10 |
4 |
| |
| |
06120-NL9-000 |
ENGINE POWER UP KIT II (for Superbike Race)
|
1 |
| 1 |
13101-NL9-000 |
PISTON |
4 |
| 2 |
13121-NL9-003 |
RING,PISTON TOP 75x0.8x2.3 |
4 |
| 3 |
13131-NL9-003 |
RING,PISTON 2ND 75x0.8x2.4 |
4 |
| 4 |
13141-NL9-003 |
RING,PISTON OIL 75x1.5x1.95 |
4 |
| 5 |
13112-NL9-000 |
CLIPS,PISTON PIN 17MM |
8 |
| 6 |
14711-NL9-000 |
VALVE,INLET(29) |
8 |
| 7 |
14721-NL9-000 |
VALVE,EXHAUST (24) |
8 |
| |
| |
06130-NL9-000 |
ACG SET |
1 |
| 1 |
11333-MEL-000 |
CLAMP,ACG CODE |
1 |
| 2 |
11321-NL9-000 |
COVER, ACG |
1 |
| 3 |
31110-NL9-000 |
ROTER COMP |
1 |
| 4 |
31120-NL9-000 |
STATOR COMP |
1 |
| 5 |
90006-GHB-660 |
BOLT,FLANGE,NSHF,6x22 |
5 |
| 6 |
90006-GHB-670 |
BOLT,FLANGE,NSHF,6x25 |
3 |
| 7 |
96600-06028-00 |
BOLT,SOCKET,6x28 |
4 |
| 8 |
95701-06012-00 |
BOLT,FLANGE,6x12 |
1 |
| 9 |
90003-NL9-000 |
BOLT,FLANGE,10x35 |
1 |
| |
| |
06140-NL9-000 |
WIRE LOCKING KIT |
1 |
| 1 |
50252-GC4-830 |
BAND,SUB TANK |
1 |
| 2 |
90012-MEL-R10 |
BOLT,DRAIN PLUG 12MM |
1 |
| 3 |
15611-NF4-900 |
CAP,OIL FILLER |
1 |
| |
| |
06150-NL9-900 |
PLUG SET,WATER HOSE |
1 |
| 1 |
19504-KY1-003 |
CLAMP,WATER HOSE D25 |
2 |
| 2 |
19512-NL8-700 |
PLUG,HOSE 16MM |
2 |
| 3 |
19511-NL3-650 |
PLUG,FAST IDLE |
2 |
| 4 |
90454-ZV1-000 |
WASHER,THRUST |
1 |
| |
| |
06160-NL9-000 |
AIR FUNNEL SET |
1 |
| 1 |
17240-NL9-000 |
WASHER COMP,TOUNGUED |
2 |
| 2 |
17215-NL9-000 |
FUNNEL,AIR#1 |
1 |
| 3 |
17216-NL9-000 |
FUNNEL,AIR#2 |
1 |
| 4 |
17217-NL9-000 |
FUNNEL,AIR#3 |
1 |
| 5 |
17218-NL9-000 |
FUNNEL,AIR#4 |
1 |
| |
| |
06195-NL3-650 |
PLUG SET,EXHAUST A/I |
1 |
| 1 |
19505-KS6-700 |
CLAMP,A WATER HOSE |
3 |
| 2 |
96205-14012 |
PLUG, CONE TYPE 14x12 |
3 |
| |
| |
06210-NL9-000 |
TRANSMISSION SET |
1 |
| 1 |
23211-MEL-R10 |
SHAFT,MAIN |
1 |
| 2 |
23220-MEL-R10 |
SHAFT COMP, COUNTER |
1 |
| 3 |
23421-MEL-R10 |
GEAR, C-1 |
1 |
| 4 |
23431-MEL-R10 |
GEAR, M-2 |
1 |
| 5 |
23441-MEL-R10 |
GEAR, C-2 |
1 |
| 6 |
23451-MEL-R10 |
GEAR, M-3 M-4 |
1 |
| 7 |
23461-MEL-R10 |
GEAR, C-3 |
1 |
| 8 |
23481-MEL-R10 |
GEAR, C-4 |
1 |
| 9 |
23491-MEL-R10 |
GEAR, M-5 |
1 |
| 10 |
23501-MEL-R10 |
GEAR, C-5 |
1 |
| 11 |
23511-MEL-R10 |
GEAR, M-6 |
1 |
| 12 |
23521-MEL-R10 |
GEAR, C-6 |
1 |
| 13 |
23442-MS2-610 |
COLLAR,30x11.2 |
1 |
| 14 |
23482-MR7-000 |
COLLAR, SPLINE,28x13.5 |
1 |
| 15 |
37700-MEL-R10 |
SENSOR ASSY,SPEED |
1 |
| |
| |
06220-NL9-000 |
DRIVE SPRKT SET |
1 |
| 1 |
23801-NL6-700 |
SPROCKET,DRIVE,15(525) |
1 |
| 2 |
23802-NL6-700 |
SPROCKET,DRIVE,16(525) |
1 |
| 3 |
23803-NL6-700 |
SPROCKET,DRIVE,17(525) |
1 |
| 4 |
90004-492-010 |
SPL..BOLT,FLANGE,6x22 |
1 |
| 5 |
90402-NL6-000 |
WASHER,10.2x37x3 |
1 |
|
